Machinable Hexagonal Boron Nitride Ceramic Products

H-BN Boron Nitride has an excellent perform in high temperature, high electrical resistivity, chemical inertness, and machinability. These characteristics allow its use for various industries. With the extraordinary machinability, we can produce all types of customized shapes.
  • Density :

    2.0 - 3.0 g/cm3
  • Max. Service Temp. :

    900 - 2,000 degree C
  • Thermal Conductivity :

    30 - 80 W/m.K
  • Dielectric Strength :

    35 KV/mm
Inquiry now
Product Detail

▼ Introduction of Hex Boron Nitride

Stable and reliable in extreme high-heat environments, Hot Pressed Hexagonal Boron Nitride ceramics are designed to excel in applications such as plasma arc welding and semiconductor processing equipment. With its unique combination of electrical insulation and thermal conductivity, Hot Pressed Boron Nitride ceramics are an excellent choice to consider for use as heat sinks in high-power electronic applications. BN - Boron Nitride is inorganic, inert and not wet by most molten metals, performing well in molten metal processes. Available in a variety of standard and custom shapes, Hexagonal Boron Nitride are easily machined, thermally shock resistant and chemically compatible across a wide range of demanding manufacturing applications.


▼ Features of Boron Nitride Ceramics

  Good Electrical Insulator
  Easy Machinability
  Good Chemical Inertness
  Good Thermal Conductivity
  High Working Temperature
  Non-wetted by Molten Metal
  Excellent Thermal Shock Resistance
  Outstanding Lubricating Properties


▼ Applications of hBN Ceramics

  CVD Crucibles    Microwave Tubes
  Low Friction Seals    Sputtering Targets
  Plasma Arc Insulators    Microcircuit Packaging
  Vacuum Melting Crucibles    Sealing, Brazing, and Metallizing Fixtures
  High Temperature Furnace Fixtures and Supports    Horizontal Continuous Casting Break Rings
  Doping Wafers in Silicon Semiconductor Processing    Electronic Parts(Heat Sink, Substrate, Coil Form...)





● For Hall Effect Thruster
● For Horizontal Continuous Casting
● For Solar and Photovoltaic Industry






● As Melting Crucibles and Liners
● For High Temp. Vacuum Furnaces
● For Metal Powder Gas Atomising


▼ Properties of Solid Boron Nitride



Hexagonal Boron Nitride can be machined into highly complex geometries with very tight tolerances. Unipretec has years of experience creating custom boron nitride components by CNC machining.

Unipretec is your Boron Nitride machining specialist for your technical ceramic prototyping & manufacturing needs; we are always happy to use our many years of advanced ceramics experience to provide advice on materials, design, and application. If you would like to buy Boron Nitride platesblocksrodstubes, or custom machined parts, please contact us and one of our experts will be happy to assist you.


Request a free quote

If you have questions or suggestions, please leave us a message,we will reply you as soon as we can!

Hot Products
  • zirconia frac plug button

    ZrO2 Zirconia Ceramic Frac Plug Buttons

    Zirconium dioxide, also known as zirconia and zirconium oxide, is a crystalline metal oxide that has found its way into the technical advanced ceramics industry. It is characterised by its high thermal resistivity, mechanical resistance, and abrasive properties.

  • Alumina Ceramics

    Alumina Ceramic Piston for High Pressure Washer Pump

    The ceramic pistons are made using the advanced aluminum oxide ceramic material that possesses high hardness, wear resistance, high temperature resistance, and corrosion resistance, ensuring consistent material performance.

  • boron nitride chamber

    Boron Nitride Plasma Chambers for Hall Effect Thrusters

    One common application for boron nitride is channels used in Hall-effect thrusters for satellites. A hall effect thruster combines an electric field with a magnetic field to ionize a gas flow to generate plasma. The electric field inside an annular channel accelerates the ions in the plasma to very high exhaust velocities.

  • boron nitride crucible

    BN Boron Nitride Crucible Liner

    Crucibles made of BN Boron Nitride are not wetted by molten metal liquids and can be used at temperature up to 2,000 degree C. BN ceramic crucibles own outstanding thermal shock resistance and are also non-electrically conductive. Choosing BN crucibles can bring you high quality sintering and long use life.

  • Ceramic Weld Pins

    Si3N4 Silicon Nitride Ceramic Welding Guide Pins

    Technial Ceramics are used to make the welding guide pins, which are used for projection welding and resistance welding in automotive industry. Ceramic pins are electrical insulated and high thermal shock resistant. Besides, they can be used up to 1,200 degree C. So they offer much longer service life and higher economic efficiency.

  • Alumina ceramic sintering aid for MIM

    High Purity Alumina Ceramic Sintering Furnace Plate

    Ceramic kiln furniture has two basic properties - firstly dimensional stability at high temperatures and secondly thermal shock resistance. UNIPRETEC is professional manufacturer of High Purity Alumina Ceramic Kiln Furniture(Trays, Setter Plates, Saggers).

Related products
boron nitride setter plate
High Purity BN Boron Nitride Setter Plate for Sintering Silicon Nitride Substrate
Boron Nitride can be compared to graphite thanks to lubrication capacities, good thermal conduction and easy machinability, although it's white and has good electrical insulation. Plus, it isn't wetted by most molten metals and can therefore be used as a container for most molten metals.
boron nitride parts
Solid Sintered Boron Nitride Ceramic Parts
Parts made of Hexagonal Boron nitride are critical components in applications where excellent thermal shock resistance, high electrical resistivity and chemical and corrosion resistance is required. BN Boron Nitride can be machined into close tolerance and complex parts.
boron nitride tube
Hexagonal Boron Nitride Ceramic Tube
BN Boron Nitride is made by hot pressing at high temperature and pressure. It can easily be machined into custom shapes. The unique combination of highly exceptional thermal, physical and chemical properties of BN makes it ideal for solving tough challenges in various industrial applications.
boron nitride ring
Hot Pressed Hexagonal Boron Nitride Ceramic Ring
Boron Nitride can be compared to graphite thanks to lubrication capacities, good thermal conduction and easy machinability, although it's white and has good electrical insulation. Plus, it isn't wetted by most molten metals and can therefore be used as a container for most molten metals.
boron nitride plate
Hot Pressed Hexagonal Boron Nitride Ceramic Plate
H-BN Boron Nitride has an excellent perform in high temperature, high electrical resistivity, chemical inertness, and machinability. These characteristics allow its use for various industries. With the extraordinary machinability, we can produce all types of customized shapes.
boron nitride crucible
Hexagonal Boron Nitride Ceramic Crucible
Crucibles made of BN Boron Nitride are not wetted by molten metal liquids and can be used at temperature up to 2,000 degree C. BN ceramic crucibles own outstanding thermal shock resistance and are also non-electrically conductive. Choosing BN crucibles can bring you high quality sintering and long use life.
boron nitride chamber
Boron Nitride Plasma Chambers for Hall Effect Thrusters
One common application for boron nitride is channels used in Hall-effect thrusters for satellites. A hall effect thruster combines an electric field with a magnetic field to ionize a gas flow to generate plasma. The electric field inside an annular channel accelerates the ions in the plasma to very high exhaust velocities.
boron nitride sleeve
HBN Hot Pressed Hexagonal Boron Nitride Ceramic Sleeve
BN Boron Nitride is made by hot pressing at high temperature and pressure. It can easily be machined into custom shapes. The unique combination of highly exceptional thermal, physical and chemical properties of BN makes it ideal for solving tough challenges in various industrial applications.
