Si3N4 Silicon Nitride Ceramic Hook for Hot Dip Aluminising

In the molten metal handling industry, hot-dip aluminising is a process for improving the metals' corrosion and wear resistant properties, Ceramic Hooks made of Silicon Nitride is used in this process.
  • Density :

    3.3 g/cm3
  • Max. Service Temp. :

    1200 degree C
  • Thermal Conductivity :

    27 W/m.K
  • Dielectric Strength :

    20 KV/mm
Inquiry now
Product Detail

In the molten metal handling industry, hot-dip aluminising is a process for improving the metals' corrosion and wear resistant properties, Ceramic Hooks made of Silicon Nitride is used in this process. Si3N4 Ceramic is chemical inert, thermal shock resistant and non-wetted by most non-ferrous metals. Besides, 1200 degree C is the max. working temperature of Silicon Nitride Ceramic. So Si3N4 Ceramic Hooks is a cost effective choice for the application of hot-dip alumising. UNIPRETEC is able to manufacture a wide range of hooks, customized design is also available.


Advantages of Si3N4 Silicon Nitride Ceramic


  Extreme hardness
  Light / low density
  High wear & corrosion resistance
  Non-wetted by molten metal
  Excellent thermal shock properties
  Coefficient of thermal expansion close to Silicon
  High working temperature up to 1200 degree C
  ...

Technical Properties of Si3N4 Silicon Nitride Ceramic


Request a free quote

If you have questions or suggestions, please leave us a message,we will reply you as soon as we can!
